Post-processing rendered images

The standard render window includes built in support for cloning, saving to High-Dynamic-Range formats, post effects, zooming and channel display.

Toolbar

Clone Window

Causes the current render window to be cloned to a second window. All channels and post-effect settings are preserved.

Save As

Saves the rendered image to an image file. The render window also contains built in support for HDRi and OpenEXR output, but these formats need to be enabled by the renderer.

File types supported
  • Windows Bitmap (.bmp)
  • JPEG - JFIF Compliant (.jpg, .jpeg, .jpe)
  • Portable Network Graphics (.png)
  • Tagged Image File Format (.tif, .tiff)
  • Truevision Targa (.tga)
  • HDRi files (.hdr, .hdri)
  • OpenEXR files (.exr)
  • Rhino Renderings (.rimage)
Copy

Copies the image to the Clipboard.

Show RGB Channels

Shows all of the color components in the image.

See: Wikipedia: Channel (digital image).

Show RGBA channels

Shows all of the color components and displays the transparent background as a grid.

Show Red Channel

Displays only the red component.

Show Green Channel

Displays only the green component.

Show Blue Channel

Displays only the blue component.

Show Alpha Channel

Displays only the alpha (transparency) component.

See: Webopedia: Alpha channel.

Show Depth Channel

Displays the z-buffer (depth information ) as grayscale.

See: Wikipedia: Z-Buffering.

Show Normals Channel

Displays Normal directions with RGB colors.

If the normal direction of a planar face points to the World +X direction, the face displays pure red.

World +X=Red, +Y=Green, +Z=Blue.
Open Effects Panel

Opens the Effects Panel where you can adjust the image exposure and add post-processing effects.

Stop Rendering

Aborts the rendering process.

Pause

Pauses and resumes the rendering process.

File menu

Clone Window

Makes a copy of the current render window. All channels and post-effect settings are preserved.

Open

Opens a saved Rhino Rendering file (.rimage). This format is a lossless format that includes all channels. These files can be opened later for adding post-processing effects.

Save As

Saves the rendered image to an image file. The render window also contains built in support for HDRi and OpenEXR output, but these formats need to be enabled by the renderer.

File types supported

  • Windows Bitmap (.bmp)
  • JPEG - JFIF Compliant (.jpg, jpeg, .jpe)
  • Portable Network Graphics (.png)
  • Tagged Image File Format (.tif, .tiff)
  • Truevision Targa (.tga)
  • HDRi files (.hdr, .hdri)
  • OpenEXR files (.exr)
  • Rhino Renderings (.rimage)
Recent

Opens recently rendered images. These images are saved automatically in Rhino Rendering (.rimage) file format.

Close

Closes the Render Window.

Edit menu

Copy

Copies the image to the Clipboard.

View menu

Toolbar

Shows/Hides the toolbar.

Effects Panel

Opens the Effects Panel where you can adjust the image exposure and add post-processing effects.

Show Rendered Image

Shows/Hides the image.

Zoom

Zooms the image, increasing or decreasing the pixel size in the window.

Channels
Default (RGB)

Shows all of the color components in the image.

See: Wikipedia: Channel (digital image).

RGBA

Shows all of the color components and displays the transparent background as a grid.

Red

Displays only the red component.

Green

Displays only the green component.

Blue

Displays only the blue component.

Alpha

Displays only the alpha (transparency) component.

See: Webopedia: Alpha channel.

Z-Buffer

Displays the z-buffer (depth information ) as grayscale.

See: Wikipedia: Z-Buffering.

Normals

Displays Normal directions with RGB colors.

If the normal direction of a planar face points to the World +X direction, the face displays pure red.

World +X=Red, +Y=Green, +Z=Blue.

Help menu

Displays the Help topic for the current renderer.

Effects panel for Render Window

Controls the post-processing effects available for the rendered image.

Load post effects from document

Reverts post effect settings to the state of the last save.

Save post effects to document

Saves the current post effect settings to the 3dm file.

Show this panel by default

Opens the Effects panel in new render windows.

Post Effects tab

The Post Effects tab lists all of the selected post-processing effects.

To add a post effect

  1. Click the button.

  2. Select a post effect from the list.

To remove a post effect

  • Click the X button behind the post effect.

To enable or disable a post effect

  • Click on the checkbox in front of the post effect.

To reorder post effects

  • Drag a post effect up or down.

    Post effects are executed from top to bottom.

Curves

Determines whether curves are displayed in the render window.

Surface edges and isocurves

Determines whether surface edges and isocurves are displayed in the render window.

Points and point clouds

Determines whether point objects and point clouds are displayed in the render window.

Dimensions and text

Determines whether dimension and text objects are displayed in the render window.

Bloom

The Bloom post-effect feathers the bright areas in an image to simulate lights in a dark scene.

Emission materials with/without the Bloom post-effect.
Brightness threshold

The Bloom effect happens when pixels are brighter than this value.

Moving the slider towards the left will add more bloom effect to the image.

Radius

The Radius setting controls the feathering distance from the bright area.

Intensity

The Intensity setting changes the brightness of the bright area. The strength falls off towards the feathering boundary.

  • Move the slider to change the value.

  • Double-click the slider to enter a number.

  • Drag the slider past the right end to increase the max value.

Glow

Produces a bright area around specific colors. It can be used to make colored lights or objects appear to glow and works well with neon type lights.

Glow Properties

Radius

Determines the radius of the glow around the bright pixel. Increasing the radius blurs the glow effect.

  • Move the slider to change the value.

  • Double-click the slider to enter a number.

  • Drag the slider past the right end to increase the max value.

Intensity

Changes the brightness of the glow color.

On

Turns on the glow effect for the color.

Color
  • Click the color swatch to pick a color from the Select Color dialog.
  • More color actions

    Click the small triangle of the color swatch for more color actions.

    Color Picker

    Opens the Select Color dialog.

    Eye Dropper

    Picks a color from anywhere on the screen.

    Copy

    Stores the current color to Clipboard.

    Paste

    Pastes the color from Clipboard.

    Sensitivity

    Controls how much variation on the selected color is permitted when calculating glow on pixels close to that color.

    Add

    Adds a new glow color. Up to 8 colors can be used.

    Delete

    Deletes the last glow color.

    Fog

    The fog effect adds depth-dependent coloration in the image and can be used to add anything from a thick fog effect to a subtle depth cue. In this way it is similar to the environment based Haze, but instead of being rendered at raytrace time, it is added afterward and can be adjusted in real time.

    Fog Properties

    Strength

    Determines the maximum amount of fogginess. 0.0 means no fog at all (and therefore no effect), 1.0 represents total fog. Values higher than 1.0 can be used but only make sense when used with noise.

    Fog Color

    Adjusts the color of the fog.

    Pick

    Picks the color from the rendered image.

    Click the image to pick a color.

    Start distance

    Specifies the distance from the camera at which the fog begins to appear.

    Pick

    Picks the depth from the rendered image.

    End distance

    Specifies the distance from the camera at which the maximum amount of fogginess is achieved.

    Pick

    Pick the depth from the rendered image.

    Pick Area

    Pick the area in the image.

    Fog Background

    Determines whether the background image is also made foggy. The background will be fogged at the maximum strength.

    Feathering

    Determines the number of pixels outside the bounding area to fade in the fogginess.

    Preview the effect on the image as you change the values in the dialog box.

    Depth of Field

    Blurs the image depending on the distance from the camera.

    Depth of Field Properties

    Blurring Strength

    Determines the amount of blurring. This is an arbitrary value and you will find different values will work better with different images.

    Max Blurring

    Determines the maximum Gaussian blurring radius used. Since extremely blurred areas can cause the effect to be slow, this limits the effect.

    Focal distance

    The distance from the camera at which the image is not blurry – in focus.

    Pick

    Pick the distance from the rendered image.

    Blur background

    Determines whether the background is blurry. The background will be blurred at the maximum effect.

    Multiplier





    Intel denoiser

    A CPU based denoiser which works on mostly any system irrespective of CPU and GPU brands. Works on Windows and Mac.

    Max Memory

    The maximum memory can be used by the denoiser plug-in.

    Information

    Error messages of the denoiser display here.

    NVIDIA denoiser

    A GPU based denoiser which works only with NVIDIA GPUs on Windows.

    Information

    Error messages of the denoiser display here.

    Which denoiser should you use?

    The Intel denoiser is generally recommended, unless you use a Windows system with an NVIDIA display card in which case the NVIDIA denoiser is recommended.

    Tone Mapping tab

    Tone mapping is the process of converting an high-dynamic-range image into a low-dynamic-range image. HDR means the pixel values can have red, green, and blue values that can be represented by a 32-bit floating point number. These values can either be smaller than 1 which means there will be a quantizing error (fixed using dithering), or they can be above 1.0 which might mean they are brighter than the maximum value of the color channel on a monitor (for example, more than 255).

    When values are "brighter than white," they will be burned out on the screen. They can be brought back into the screen/bitmap color gamut using tone mapping, which is the process of remapping the color in an image so that the brighter areas are better represented. The options offer a number of ways of doing this.

    See: Wikipedia: High dynamic range imaging.

    Black / White point

    Linear interpolation between two points that are specified as black and white. In a normal image, these are 0.0 and 1.0.

    Black point

    Specifies the numerical value for the black point.

    White point

    Specifies the numerical value for the white point.

    Logarithmic

    Changes the response curve to a power function so that the upper range is slowly given less prominence. It is based on logarithmic compression of luminance values, imitating the human response to light.

    See: Adaptive Logarithmic Mapping For Displaying High Contrast Scenes, by F. Drago, K. Myszkowski, T. Annen and N. Chiba.

    Histogram

    A graphical representation of the tonal distribution in a digital image. It plots the number of pixels for each tonal value. By looking at the histogram for a specific image, you can judge the entire tonal distribution at a glance.

    See: Wikipedia: Image histogram

    Final Pass tab

    Gamma

    Image files are color corrected so that they can be loaded byte-by-byte into the RGB pixels of a computer screen and look right on a monitor. This means that the color response of a standard image is non-linear, that is, it is gamma corrected. Gamma refers to the power function that is used to correct the image. The Gamma value changes, and therefore corrects the output of the image.

    • The Gamma post effect is disabled when the renderer does not support Linear Workflow.

    Gamma less than 1 (left), at 1 (center), and greater than 1 (right).

    See: Wikipedia: Gamma correction.

    Dithering

    In some occasions, a color banding issue might happen in renderings. It is possible to be fixed by turning Dithering on.

    Color banding in a rendering.
    Color banding removed by Dithering.

    See: Wikipedia: Dither.

    None

    No dithering is applied.

    Floyd-Steinberg

    Commonly used algorithm by image manipulation software, for example when an image is converted into GIF format that is restricted to a maximum of 256 colors.

    Simple Noise

    Randomly applied noise.

    Watermark

    Adds a text block to the lower-left corner of the rendering image about when the rendering started, ended, and the time elapsed.

    Font

    The font used for the watermark text.

    Font Size

    The height of the watermark text in pixels.

    Font Color

    The color of the watermark text.

    Transparency

    The visibility of the watermark text block.

    Hue/Saturation/Luminance

    Hue

    Adjusts the material color after rendering.

    The idea is this way you can try different color combinations without having to re-render the whole scene.

    Since the hue adjuster works on the pixels of the rendered image, it has no knowledge of what contributed to the color of the pixel other than the topmost object. For example reflections of the object on other objects and parts of the object seen through transparent objects will not update.

    Sat

    Sets the saturation amount. The smaller the saturation, the more monochromatic the image.

    Lum

    Sets the luminance amount.

    Brightness/Contrast

    Bri

    Changes the overall brightness of the image.

    Con

    Increasing contrast makes dark pixels darker and bright pixels brighter. Colors in the image will be more distinguishable.

    Decreasing contrast changes colors towards the neutral gray. The image will look less sharp.

    Noise

    Noise adds noise to the image. By default RGB channels are separated, so adding noise to a gray-scale image makes individual pixels shift towards random color.

    Monochromatic

    Only the darkness/lightness of the pixel is altered. The color stays the same.

    Gaussian blur

    Adds Gaussian blur to the image. The number is the radius of the blur kernel, equivalent to the same setting in paint applications.

    Horizontal

    Specifies the blurring to be horizontal. This can be used to create a horizontal motion blur effect.

    Vertical

    Specifies the blurring to be vertical. This can be used to create a vertical motion blur effect.

    Both

    Blurs in both directions.

    Rhino Image File Format (.rimage)

    Rhino Render can save .rimage files. This is a proprietary file format that stores all of the information rendered by the rendering engine, including color, alpha, depth, normal channels, all with 32-bit per-channel resolution.

    This information is used by the render window to execute the post-effects and exposure operators, and can also be used by custom controls implemented by a third-party renderer to achieve other effects.

    Immediately after render time, the .rimage format can be used to store the data so that post-processing and exposure adjustments or format changes (saving in a different format without loss of information) can be done later.

    The .rimage format is only supported by the Rhino render window. It cannot be loaded into any other software. It is a high-dynamic range format that supports lossless information transfer to .HDR and .EXR formats. It is uncompressed and the files can be huge.

    To open an .rimage file

    • In the Rhino render window, on the File menu, click Open.
      Or
    • Use the RenderOpenRenderImage command to open an .rimage file without having a render window open.

    Completed renderings are saved in the .rimage format to a temporary location on your hard disk. Once one of the renderings is re-opened, all post effects and exposure settings are available as if the rendering were just completed.

    To open the most recent .rimage file

    • In the Rhino render window, on the File menu, click Recent, and then choose a file.
      The files are named the by date and time of the rendering.

    For more information about post processing the rendered image, see: Post-processing rendered images.

    See also

    Render your model scene

    Add lights for rendering

    Use materials and textures
